Jovy kapton tape is a silicone adhesive tape based on polyimide, featuring Excellent Heat resistance, designed for the usage of electrical masking series.
It is ideal for wave soldering, insulating circuit boards and high temperature powder coating. It has a high dielectric strength. The Kapton tape is supplied with a silicone adhesive which doesn’t leave any residue. It can hold temperature up to 500o F/260o C.
Jovy systems heat resistant tape does not soften at high temperatures. It is recommended to be used when the target component is enclosed with adjacent components, as the Kapton Tape protects undesired areas from the extra heating during the soldering process.
Kapton tape features:
• Heat Resistant tape, resist temperatures up to 260°C .
• Coated with a silicone adhesive which doesn’t leave any residue.
• Protects the adjacent component from the high temperature.
• Remains stable across a wide range of temperature.
• Available in 30 meter rolls.
Product structure:
*Backing: Pl Film.
*Color: Amber.
*Heat resistance : – 730C to 2600C
*Backing thickness: 0.025mm+0.005mm.
*Total thickness:0.060mm+ 0.005mm.
*Roll:30mm x 33m
Shelf Life :In order to obtain the best performance, use this product within 6 months from date of delivery and store under normal storage conditions of 27°C-35°C and 40% to 60% R.H. in the original package.
